Hydraulic Valving

We have a range of installation valves to guarantee easy setup and operation of our equipment. From pressure and flow restrictors to load sensing and priority valves, we have a large range of options to cover every application. We also offer a modular system which is a combination of different valve blocks that are sandwiched together providing endless possibilities.

Features:

• Priority Valve (PV-SAE) is used when you need to establish a new hydraulic line for a piece of hydraulic equipment. The valve prioritises the hydraulic oil flow to a piece of hydraulic equipment e.g. HG Hydraulic Generator. The priority valve has an integrated pressure limiter that protects the piece of hydraulic equipment from pressure peaks. It enables the simultaneous use of the carrier machine’s basic manoeuvres and usage of the piece of hydraulic equipment.
• Load Sensing Valve (LSV) senses the need for hydraulic oil flow. It controls the amount of hydraulic oil flow that is led to the piece of hydraulic equipment. The Load Sensing Valve has an integrated pressure limiter that protects the piece of hydraulic equipment from pressure peaks.
• Solenoid Valve (SV & SV-SAE) is for controlling your piece of hydraulic equipment. Solenoid Valve makes hydraulic oil flow electrically controllable.
• Flow Limiter Valve (VR) limits the hydraulic oil flow to the required level for the installed piece of equipment.

Options:

• 12 or 24 volt options.
• Custom designed solutions for any application.
• Stepless pressure and flow limits set at factory.
