Specifications:
| Model | Excavator Size | Weight | Hydraulic Couplers | Pin Centres | Width |
| (ton) | (kg) | (mm) | (mm) | ||
| OQ40 | 1 - 5 | 32 | 2 x 3/8" & 2 x 1/2" | 300 | 240 |
| OQ45 | 5 - 12 | 85 | 3 x 3/8" & 2 x 1/2" | 430 | 290 |
| OQ60 | 8 - 18 | 135 | 2 x 3/8", 1 x 1/2" & 2 x 3/4" | 480 | 340 |
| OQ65 | 14 - 22 | 170 | 2 x 3/8" & 3 x 3/4" | 530 | 440 |
| OQ70 | 15 - 28 | 210 | 2 x 1/2", 1 x 3/4" & 2 x 1" | 600 | 450 |
| OQ70-55 | 18 - 32 | 230 | 2 x 1/2", 2 x 3/4" & 2 x 1" | 600 | 550 |
| OQ80 | 24 - 43 | 320 | 2 x 1/2", 2 x 3/4" & 2 x 1" | 670 | 590 |
| OQ90 | 40 - 70 | 630 | 3 x 1/2", 1 x 3/4" & 4 x 1" | 750 | 750 |
| OQ120 | 70 - 120 | 1,200 | 3 x 1/2", 3 x 1" & 2 x 1 1/2" | 925 | 870 |
Resources
Automatic Quick Couplers
Integrated hydraulic performance
Boasting the world’s most popular and advanced fully automatic quick coupler system. These quick couplers fully integrate hydraulic
connections between machine and attachment, massively increasing productivity on the job site.
Features:
- Protected hose routing on machine and attachments.
- Switch hydraulic attachments in seconds.
- Automatically connect hydraulic connections.
- Eliminates oil leaks.
- Heavy-duty welded construction.
- Increased safety, productivity and profitability.
- Compact profile maximises breakout force.
- Safety locking sensors and system.
